Short Description:




  • FOB SHENZHEN: To be negotiated
  • MOQ: 100 Pieces
  • Supply Ability: 3000000 Pieces/Month
  • Payment Terms: L/C,D/A,D/P,T/T
  • Lead Time: 7-20 Days
  • Brand Name: Leader
  • Construction: Permanent Magnet
  • Protect Feature: Totally Enclosed
  • Technical Datas: Can be customized
  • Product Detail

    Product Tags

    Place of Origin Guangdong, China (Mainland)
    Model Number LD8404E2
    Usage Mobile phone, Watch and Band,Massagers,Medical apparatus and instruments
    Certification ISO9001,ISO14001,OHSAS18001
    Type Micro Motor
    Commutation Brush
    Feature Vibration
    Rated speed 11000±2500rpm
    Rated current 105 mA Max
    Starting voltage 2.0(V) DC Max
    Rated voltage 3.0(V )DC
    Operating voltage 2.7~3.6(V) DC
    Life 3.0V,1S ON,1S OFF, 200,000 cycles

    E2

    1616725477

    COMPANY PROFILE

    立得公司

    金寨公司

    Leader is a manufacturer in Micro Coin Motor.
    Established in 2007, Leader Microelectronics (Huizhou) Co., Ltd. is an international enterprise integrating R & D, production, and sales.
    In 2015, we established a branch company in Anhui province, called Jinzhai Leader Micro Electronics Co., Ltd to meet the growth of the order.

    We mainly produce coin motor, linear motor, brushless motor, coreless motor, SMD motor, Air-modeling motor, deceleration motor and so on, as well as the micromotor in the multi-field application, which are widely used in mobile phone, wearable device, massagers, e-cigarette and so on.
    We have 4 automatic production lines of the coin motor (Production Capacity 5KK/month), 2 lines of brushless motor and linear motor(2KK/month), and 1 line of bar-type motor.

    Quality system and R & D strength.
    We have passed ISO9001:2015 international quality management system, ISO14001:2015 environment management system , and OHSAS18001:2011 occupational health and safety management system, to ensure the superiority of product quality and the stability of product performance.
    We also have the most advanced production and testing equipment at present and technically at the leading level in the domestic and foreign industries.

    There are 12 staffs in our R & D team, some of whom have more than 10 years experience in micro motor technology and we have our processing workshop to produce JIG by ourselves to meet the newly developed products requested by our customers.

    CERTIFICATIONS

    1616726047(1)

    1616725949(1)

    PRODUCT TEST EQUIPMENT

    1616726149(1)

    PACKING & DELIVERY

    1. 100mini dc drive motors in each PS tray.
    2. Every 20 capsules as a group, put a plastic cover on the group and wrap it in tape.
    3. Put the wrapped group into a inbox.
    4. Every 8 inboxes are put into an outer case by the ways standard as the drawing.
    5. Quantity and batch number are written on the surface of the outer case.

    1616726294(1)

    1616726354(1)

    OUR ADVANTAGES

    1.Continuously improve production automacity 35 of 47 existing process has been realized automation, achieving an automation rate of 75%.

    2. No pure manual work For projects hard to automate, Jigs have been used to assist in flexible manufactures.

    3. Optimize production jigs In order to reduce delivery time, most manufacturing facilities are designed and manufactured by ourselves, including 30% equipments and 90%+ jigs.

    4. Continuously improve production efficiency Efficiency increases by 10% averagely in recent years

    5. Pay high attention to safety in production

    1616726457(1)



    主要客户

     FAQ

    Q1. Can you produce according to the samples?
    A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

    Q2. What is your sample policy?
    A: We can provide free sample, but the customers have to pay courier cost.

    Q3. Do you test all your goods before delivery?
    A: Yes, we have 100% test before delivery

    Q4: How do you make our business long-term and good relationship?
    A:1. We keep good quality and competitive price to ensure our customers benefit ;
    2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.

    Q5: What kind of motors you can provide?
    A: Our main products are coin motor, linear motor, bldc motor which are applied in mobile phone, wearable devices, massagers and so on.

    Q6: Is there a MOQ for your motors?
    A: Yes, our MOQ is 100PCS.

    Q7: Is it possible for you to develop new motors if we provide the tooling cost?
    A: Yes. Please kindly share the detailed requirements like performance, size, annual quantity, target price etc. Then we’ll make our evaluation to see if we can arrange or notQ8: Which shipping way is available?
    A: DHL, UPS, FedEx, TNT, EMS, China Post,Sea are available.The other shipping ways are also available, please contact us if you need ship by the other shipping way.

    Q9: How long is the deliver[Producing] and shipping?
    A: Deliver time depends on the quantity you order. usually it takes 15-25 working days.

    Q10: How to confirm the payment?
    A: We accept payment by T/T, PayPal, the other payment ways also could be accepted,Please contact us before you pay by the other payment ways. Also 30-50% deposit is available, the balance money should be paid before shipping.


  • Previous:
  • Next:

  • Brief Introduction of Coin Motor:

    Leader Micro Electronics currently produces coin vibration motors, also known as pancake vibrator motors with diameters of  Ø7mm-Ø12mm.

    Coin motors are convenient to use and can be affixed in place with a strong permanent self-adhesive mounting system.

    For coin motor, we offer both leaded and spring & pad mountable versions. The wire length can be modified and the connector can be added as required.

    _SGS5410

    1616725077(1)



    Main Features of Micro Coin Motor:

    • Small Size, Easy Mounting In Haptic Device.
    • Low Noise Level When Vibrating Feedback.
    • Rated At 3 VDC, Offer A Low-Power Solution For Vibrating.
    • Rotates Both Cw And CCW Easily Used And Installation.
